| Model |
DH-HAC-HDBW2120RP-Z |
DH-HAC-HDBW2120RN-Z |
| Camera |
| Image Sensor |
1/3" 1.4Megapixel CMOS |
| Effective Pixels |
1305(H)×1049(V) |
| Electronic Shutter |
1/3s~1/100,000s |
| Video Frame Rate |
25/50fps@720P |
30/60fps@720P |
| Synchronization |
Internal |
| Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
| Video Output |
1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch) |
| Camera Features |
| Max. IR LEDs Length |
30m(60m optional), Smart IR |
| Day/Night |
Auto(ICR) / Color / B/W |
| Noise Reduction |
2D/3D |
| OSD Menu |
Support |
| Lens |
| Focal Length |
2.7~12mm |
| Lens Type |
Motorized / Fixed Iris |
| Mount Type |
Φ14 |
| General |
| Power Supply |
DC12V±10% |
| Power Consumption |
Max 9.6W |
| Working Environment |
-30°C~+60°C / Less than 95%RH (no condensation) |
| Transmission Distance |
Over 500m via 75-3 coaxial cable |
| Ingress Protection |
IP66 & IK10 |
| Dimensions |
Φ122mm×89mm |
| Weight |
0.45kg |
